Honda
Safety Activity 103ki — VR Validation Instrument
{{ viewBadge }}
Condition Moto speed {{ motoSpeedSet }} kph
3D engine could not load — check network and reload.
{{ hmiIdleLabel }}
!
{{ hmiTitle }} {{ hmiSub }}
t{{ tLabel }} s head{{ yawLabel }}° / {{ pitchLabel }}° {{ gazeLabel }}
{{ stateLabel }}
{{ egoSpeedLabel }} km/h
{{ promptText }}
NEXT TRIAL IN
{{ countdownNum }}
{{ countdownNext }}
Same scenario, motorcycle speed +10 kph · Reset to stop
SESSION COMPLETE
{{ sessionDoneText }}
All trials are stored under P-{{ participantId }} · open Sessions for the evaluation
drag to look around · keys G · W · A
SPECTATOR · {{ linkLabel }}
{{ stageLabel }}
{{ spectatorPrompt }}
TIME
{{ tLabel }} s
HEAD
{{ gazeLabel }}
EGO SPEED
{{ egoSpeedLabel }} km/h
LAST DECISION
{{ lastDecision }}
{{ st.label }}
Decision-Margin Model
M = Tavailable − (Tcheck + Tdecision + Tmaneuver)
T_availT_checkT_decT_manM {{ mAvail }}{{ mCheck }}{{ mDec }}{{ mMan }}{{ mVal }}
{{ mInterp }}
ΔM = Mwith − Mwithout · {{ motoSpeedSet }} kph · {{ distLabelSet }}
{{ deltaVal }} {{ deltaNote }}
VR simulation storyboard · focus scenario: overtaking with approaching motorcycle

Simulation flow for the VR program

Actual view is from inside the cabin; the participant does not control steering or braking. Rail playback keeps every trial identical so differences in timing come from the participant, not the vehicle.

{{ s.n }}{{ s.tag }}
{{ s.img }}
{{ s.title }}
{{ s.body }}
Process flow per participant
  1. Observe traffic situation from the driver viewpoint
  2. Check road by moving head (left / right / front)
  3. Decision selection: GO / WAIT / ABORT on the controller stick
  4. Check decision result

Session 20–30 min per person including interview · 5 min interval · HPM meeting room.

Post interview
  1. When did you notice the motorcycle?
  2. Why did you select GO / WAIT / ABORT?
  3. Which information influenced you most: speed, distance, or time?
  4. Did the assistance change your decision?
  5. Was the warning too early, appropriate, or too late?
  6. What additional information would help?
Research question

Does safety information change when and how a driver recognizes a motorcycle and makes a Go/No-Go decision?

Not a driving simulator: a controlled decision-elicitation instrument producing clean, timestamped behavioural data against the Decision-Margin Model. Value is measurement fidelity and data integrity, not visual realism.

Condition 1 · Car without assistance

Participant follows a slower vehicle; motorcycle approaches from the opposite lane; GO / WAIT / ABORT. Judgement by visible distance, perceived speed, road position, available gap.

Condition 2 · Car with assistance

Same scenario with staged information: motorcycle approaching → approaching quickly → insufficient passing time, need to wait. A "safe to go" state is never shown.

Condition 3 · Motorcycle without assistance

Participant rides the motorcycle position in the same traffic, judging on their own. Enables 4W vs 2W user comparison.

Variables
Main Approaching motorcycle speed, 30 → 100 kph in +10 kph steps
Fixed Straight 2-way 2-lane road no median · clear daytime · lead vehicle · initial position · assistance location and format
Optional Near vs far initial distance
HMI staging (IOCM, >10 km/h, up to 30 m) + sound warning
StandbyKeep Focus · other vehicle rel. speed >30 kph, distance >20 m
AlertBe Aware · rel. speed >30 kph, distance 15–20 m
WarningDon't Maneuver, Reduce Speed · rel. speed >30 kph, distance <15 m

DAA (0–10 km/h, up to 20 m): Get Ready 5–20 m · Stop <5 m. In the prototype, stages are triggered by TTC (tweakable) so they are testable at overtaking closing speeds.

Data capture · synchronized device and software logs
HeadsetHead direction · left/right/front checking · number and sequence of checks · time facing motorcycle or HMI · re-check the road after warning · eye tracking movement ControllerGO button · WAIT button · ABORT trigger · decision timestamp · decision changes VR softwareMotorcycle speed and distance · relative speed · time to conflict · HMI activation time · distance and TTC at decision · virtual minimum separation
Respondents
15 × 4W users · 15 × 2W users · 30 total
Male/female combined · 22–55 y.o.
Daily 2W/4W commute · >2 years driving
Excluded: motion sickness history, visual impairment
Analysis framework
Speed · how quickly the conflict develops
Distance / gap · space before paths overlap
TTC · time remaining before the conflict
Recognition & decision time · time to notice, judge, decide
Activity schedule · Apr 2026 – Mar 2027
Study proposal → Vendor study & admin process → VR program development → Trial & evaluation → Fieldwork → Data process → Analysis & reporting
Milestones: GIIAS 30 Jul–9 Aug, GJAW (TBC), mid report, DIR/MG reviews. Week-level bars from the deck to be confirmed.
Session database · {{ syncNote }}

Participants, trials and evaluation

Participants {{ dbParticipantCount }}
No participants yet. Add one, or run a trial: it is stored under the active participant P-{{ participantId }}.
Active participant: P-{{ participantId }} · {{ participantGroup }}. New trials are saved here.
Evaluation summary · P-{{ dbSelId }}{{ dbSelGroup }} · {{ dbTrialCount }} trials
{{ k.label }}
{{ k.value }}
{{ k.sub }}
Moto speedC1 decisionC1 MC2 decisionC2 MΔM (C2 − C1)HMI → decisionC3 decision
{{ r.speed }} kph{{ r.c1 }}{{ r.m1 }}{{ r.c2 }}{{ r.m2 }}{{ r.dM }}{{ r.hmiLat }}{{ r.c3 }}
Participant evaluation · P-{{ dbSelId }}{{ evalMeta }}
{{ evalVerdict }}
{{ p.label }} {{ p.value }}
{{ f.title }}
{{ f.body }}
All participants · comparison{{ dbParticipantCount }} participant(s)
ParticipantGroupTrialsGO rate C1GO rate C2Mean ΔMRisk thresholdCollisionsHead checksProfile
P-{{ c.id }}{{ c.group }}{{ c.n }}{{ c.go1 }}{{ c.go2 }}{{ c.dM }}{{ c.risk }}{{ c.coll }}{{ c.checks }}{{ c.profile }}
Trials newest first
No trials recorded for this participant yet.
#TimeCondMotoStartDecision pathResultResp. timeT_checkT_decTTC@decChecks L/RFacing motoM
{{ t.n }}{{ t.time }}C{{ t.cond }}{{ t.speed }}{{ t.dist }}{{ t.path }}{{ t.result }}{{ t.resp }}{{ t.tCheck }}{{ t.tDec }}{{ t.ttc }}{{ t.checks }}{{ t.facing }}{{ t.m }}
Event log · {{ dbSelTrialLabel }}{{ dbSelTrialEvents }} rows
{{ e.t }}{{ e.src }}{{ e.label }}
What is evaluated mapped to the four study objectives
{{ d.title }}
{{ d.body }}
Honda
SAFETY ACTIVITY 103KI

VR Validation
Instrument

Overtaking decision study · 4W and 2W users
3 CONDITIONSMOTO 30–100 KPHSYNCED LOGWEBXR READY
INTERNAL VALIDATION BUILD · v0.2 TEKAN ENTER ↵ UNTUK MULAI
